Eventide PowerMini

Powerful & Compact Pedalboard Power Solution

PowerMini is a super-compact, isolated power supply for smaller pedalboards that ensures your pedals will achieve maximum fidelity. PowerMini provides four outputs at 600 mA (with 2 outputs switchable to 9, 12, 15, or 18V).

FEATURES

• 18VDC, up to 2A, Center Pin Positive (+), 5.5/2.1mm plug

• Mounting hardware (2 screws and a hex-key)

• Product sheet (drill guide)

• Flex & DC Link cable guide

7 Flex Cables:

• 2 x 1030 – black, 30cm, center negative, type 1 (Eventide Rose, MixingLink & BOSS type)

• 2 x 1050 – black, 50cm, center negative, type 1 (Eventide Rose, MixingLink & BOSS type)

• 2 x 4050 – green, 50cm, center positive, type 4 (Eventide all H9s, TimeFactor, ModFactor, PitchFactor & Space)

• 1 x 1533 – 3-way daisy chain, black, 50-30-30cm, center negative, type 1 (BOSS type)

SPECIFICATIONS

Connectors
Mains Input: 9-24V DC, 9-12V AC
Outlets 1-2: 9V DC / 660mA
Outlets 3-4: 9, 12, 15, 18V DC / 660mA

Physical
Size: 2.9” x 3.5” x 1.0”
Weight: 0.507 lbs / 220.9g
Warranty: 5 years worldwide
