DOD Meatbox Subsynth

Answering the call of low frequency freaks everywhere, the DOD Meatbox is an updated take on the cult favorite Meatbox from the ‘90s.

More than just an octaver, the Meatbox is a thick-cut subharmonic synthesizer as well. Adding in sub notes so low that you need to be careful not to blow your speakers. A TRS out allows you to split the subharmonic synthesized signal out to the P.A. for teeth-rattling, bone wrenching, bowel-shaking, booty-quaking bass that will rock the house, literally.

FEATURES

• Octave Control: This control is used to increase/decrease the amount of low octave being added to the signal. Turn this clockwise to increase the amount of low octave.

• Output Level Control: This control is used to adjust the output level of your signal (when the effect is on). Turn this clockwise to increase the output level.

• Sub Control: This control is used to increase/decrease the amount of Synthesized Subharmonic added to the signal. Turn this clockwise to increase the amount of Synthesized Subharmonic.

• Low Control: This control is used to increase/decrease the low frequency content of the output, this keeps the extreme lows from overwhelming your amp and speakers.

• LED Power Indicator: This lights up when the pedal is on.

• Based on the iconic DOD Meatbox circuit design with updated components

• True Bypass and new crisp blue LED status indicator

• TRS Output

SPECIFICATIONS

Input: 1¼” Instrument
Output: 1¼” TRS (Tip = Octave +Sub, Ring = Dry, Sleeve = Ground)
Chassis Material: All Metal
Power Supply: 9V Alkaline Dry Battery or optional power supply

Dimensions
Height: 2.25”
Width: 2.63”
Length: 4.68”
Weight: 0.62 lbs.
