Chauvet DJ COREpar Q60 ILS LED Wash Light

COREpar Q60 ILS is a 60-watt quad-colour (RGBA) COB (Chip-on-Board) LED that produces a full spectrum of light with unsurpassed colour mixing. Its robust housing withstands the harshness of travelling from gig to gig and its sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit for easy connections. Among the powerful features of the COREpar Q60 is ILS compatibility for use in the Integrated Lighting System (ILS) ecosystem which makes creating coordinated light shows across different fixture types easy. D-Fi USB compatibility is also a board for wireless Master/Slave or DMX control. Achieve flicker-free video operation with high-frequency LED dimming and the included magnetic Fresnel lens allows the flexibility to go from ultra-wide to narrow beam in seconds. Create customized colours using the built-in LED display and achieve smooth LED fading with built-in dimming curves.

FEATURES

• COB LED produces a full spectrum of light with unsurpassed colour mixing

• ILS compatibility for use in the ILS ecosystem

• D-Fi USB compatibility for wireless Master/Slave or DMX control

• Magnetic Fresnel lens allows ultra-wide to narrow beam in seconds

• Withstand the harshness of travelling from gig to gig with a robust housing

• Sit-flat housing design hugs the floor and features power and DMX outlets

• Achieve flicker-free video operation with high-frequency LED dimming

• Save time running cables and extension cords by power linking multiple units

• Operation of static colours and automated programs with the optional IRC-6 remote

• Create customized colours using the built-in LED display

• Achieve smooth LED fading with built-in dimming curves

• Easily transports in the optional CHS-40 VIP Gear Bag

SPECIFICATIONS

DMX Channels: 4 or 9
DMX Connectors: 3-pin XLR
Light Source: 1 COB LED (quad-color RGBW) 60 W, (2.8 A), 50,000 hours life expectancy.
Strobe Rate: 0 to 29 Hz
Beam Angle with lens: 20°
Beam Angle without lens: 74°
Field Angle with lens: 30°
Field Angle without lens: 100°
Illuminance without lens: 320 lux @ 2 m
Illuminance with lens: 2,796 lux @ 2 m
Power Linking: 9 units @ 120 V; 17 units @ 230 V
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power and Current: 59 W, 0.8 A @ 120 V, 60 Hz, 57 W, 0.5 A @ 230 V, 50 Hz
Weight: 3.4 lbs. (1.5 kg)
Size: 192 x 192 x 210 mm
Approvals: CE, RoHS, UKCA
Cable Length: 5ft (1.5 m)
Bracket Mounting Hole: 13 mm
Optional Controllers: IRC6, D-Fi USB

WHAT'S INCLUDED:

• Fixture

• Power cord

• Magnetic Lens

• Quick Reference Guide
