Charvel Pro-Mod DK24 HSH 2PT CM Mahogany Natural

The sleekly sculpted mahogany Dinky® body features a scalloped lower back bout and shredder's cut heel that make access to the upper registers seamless. The bolt-on caramelized maple "speed" neck has graphite reinforcement for sturdy stability against environmental warping and a silky-smooth hand-rubbed satin urethane finish on the back for sublime playability. Luminlay® side dots guide your way along the fretboard on even the darkest of stages, and the heel-mount truss rod adjustment wheel makes for painless neck relief tweaks. Designed for fast playing, the 12"-16" compound radius caramelized maple fingerboard features comfortable rolled edges, 24 jumbo frets, pearloid dot inlays and Graph Tech® TUSQ® XL nut.

Smooth sustain paired with warm, buttery timbre radiates from a custom Seymour Duncan® Full Shred™ TB-10 bridge pickup, Seymour Duncan Custom Flat Strat® SSL-6 single-coil middle pickup and custom Seymour Duncan Alnico II Pro™ APH-1N neck pickup. The bridge pickup emits a bright tone with a tight low end and scooped mids. The middle pickup is the perfect blend of heightened output and springy Stratocaster attitude, while the humbucking neck pickup shines with a distinct warmth that is silky and boasts incredible natural sustain.

Taking our modern DK24 platform up a notch, this 2PT model's premium modern features include a five-way blade pickup switch, Stratocaster®-style skirt knobs for the volume (with 500K EVH® Bourns® low friction potentiometer) and no-load tone controls, Gotoh® Custom 510 tremolo bridge, Charvel-branded locking tuners and more.

Sporting sophisticated style, the Pro-Mod DK24 HSH 2PT CM Mahogany is available in an all-new Natural finish with gold hardware.

FEATURES

• 25.5" scale length

• Mahogany Dinky® body with scalloped lower back bout

• Sculpted shredder's cut heel

• Bolt-on maple neck with graphite reinforcement and hand-rubbed satin urethane finish on the back

• 12"-16" compound radius caramelized maple fingerboard with 24 jumbo frets and pearloid dot inlays

• Luminlay® side dots

• Heel-mount truss rod adjustment wheel

• HSH pickup configuration featuring a custom Seymour Duncan® Full Shred™ TB-10 humbucking bridge, Seymour Duncan Custom Flat Strat® SSL-6 single-coil middle and custom Seymour Duncan Alnico II Pro™ APH-1N humbucking neck pickups

• Five-way blade switch, volume control (with 500K EVH® Bourns® low friction potentiometer) and no-load tone control

• Stratocaster®-style skirt control knobs

• Gotoh® Custom 510 tremolo bridge

• Graph Tech® TUSQ® XL nut

• Charvel-branded sealed die-cast locking tuners and standard strap buttons

• Available in Natural with gold hardware­­­­

SPECIFICATIONS

Series: Pro-mod
Orientation: Right-hand
Color: Natural
Country Of Origin: MX

Neck
Headstock: Licensed Fender® Stratocaster®
Neck Material: Caramelized Maple
Neck Finish: Hand-rubbed Satin Urethane
Neck Shape: Speed Neck With Rolled Fingerboard Edges
Neck Construction: Bolt-on With Graphite Reinforcement
Fingerboard Radius: 12"-16" Compound Radius (304.8 Mm To 406.4 Mm)
Fingerboard Material: Caramelized Maple
Position Inlays: 4mm Pearloid Dot
Side Dots: Luminlay®
Number Of Frets: 24
Truss Rod: Dual-action With Wheel
Truss Rod Nut: Heel-mount Truss Rod Adjustment Wheel
String Nut: Graph Tech Tusq Xl
Nut Width: 1.6875" (42.86 Mm)
Nut Material: Graph Tech Tusq XL

Body
Body: mahogany
Body Finish: Satin
Body Shape: Dinky®
Body Style: Solid Body
Body Material: Mahogany

Hardware
Bridge: Gotoh® Custom 510 Tremolo
Pickguard: None
Pickup Covers: Flat Black
Control Knobs: Stratocaster®-style Skirt
Switch Tip: Black
Hardware Finish: Gold
Tuning Machines: Charvel®-branded Die-cast Locking
String Trees: Fender® Standard String Guide
Strings: Nickel Plated Steel (.009-.042 Gauges)
Tremolo Arm: Gotoh®
Neck Plate: None - 4-bolt Sculpted Heel
Strap Buttons: Standard

Electronics
Bridge Pickup: Seymour Duncan® Full Shred™ TB-10
Middle Pickup: Seymour Duncan® Custom Flat Strat® SSL-6 Single-coil
Neck Pickup: Custom Seymour Duncan® Alnico II Pro™ APH-1N
Pickup Configuration:HSH
Controls: Volume (500k Evh® Bourns® Low Friction Pot), No-load Tone
Switching: 5-position Blade: Position 1. Full Bridge Pickup, Position 2. Bridge Inner Coil And Middle Pickup, Position 3. Both Inner Coils, Position 4. Neck Outer Coil And Middle Pickup, Position 5. Full Neck Pickup

Measurements
Dimensions: 4.50x15.10x42.50 In
Shipping Weight: 10.20 Lb
Fret Size: Jumbo
Scale Length: 25.5" (64.77 Cm)
Shipping Length: 42.50 In
Shipping Height: 4.50 In
Shipping Width: 15.10 In

Accessories
Saddle Height Wrench: Yes

Miscellaneous
Unique Features: Luminlay® Side Dots
