Behringer XENYX 802S

The compact XENYX 802S mixer’s 8 inputs allow you to effortlessly achieve premium-quality sound that’s perfect for streaming, podcasting and recording. It provides a warm and ultra-musical sound thanks to its award-winning XENYX microphone preamps featuring 48V Phantom Power for hi-end studio microphones.

FEATURES

• Ultra-low noise analog mixer for streaming, podcasting and recording

• 2 Award winning XENYX microphone preamps for warm and musical sound

• Stereo USB audio interface to connect your computer or mobile device

• Direct mixing of PC/gaming sounds into the streaming output

• Analog mixing and equalization for pure sound

• Versatile sub mixer for network enabled audio devices

• Stereo channel 7/8 automatically switches between TRS input and USB playback

• 3-band EQs for warm and musical sound

• FX send control per channel for external FX processor or monitoring mix

• High-quality main, monitor, phones and streaming outputs

• Stereo RCA inputs assignable to main mix or monitor/phones outputs

Great for Any Setup
The new XENYX “S” series can be connected to computers or mobile devices via USB making it super easy to integrate digital sources with analog equipment. Two mono and 2 stereo channels with EQ, plus another stereo channel, a stereo RCA streaming input and stereo USB input allow you to blend a total of 12 crystal-clear audio signals for monitoring via headphones or on high-quality TRS outputs. Hence, the 802S can also be used as a versatile sub mixer for combining network enabled audio devices with several other audio signals.

Control Made Easy
The 802S features a 3-band EQ on Mono and Stereo inputs and allows for precise sound shaping for any input source. An integrated FX send control per channel lets you plug in any external FX processor of your choice, such as the Behringer FX2000, for amazing audio effects flexibility. When nothing is plugged into the stereo line inputs 7/8, then the Level 7/8 control can be used to adjust the USB input level conveniently.

SPECIFICATIONS

Mono Inputs
Microphone Input
Balanced XLR, discrete input circuit
Mic EIN (22 Hz-22 kHz) @ 50 Ω: 132 dB, A-weighted
Frequency response Gain +10 dB: 10 Hz to 150 kHz
Frequency response Gain +60 dB: 20 Hz to 70 kHz
Gain range: +10 dB to +60 dB
Max input level @ +10 dB Gain: +12 dBu
Input Impedance: 2 kΩ balanced
Distortion (THD + N) 1 kHz @ +10 dB Gain: 0.005%

Mono Line Inputs
1/4" TRS connector balanced
Impedance: 22 kΩ balanced, 10 kΩ unbalanced
Gain range: -10 dB to +40 dB
Max input level @ 0 dB Gain: +21 dBu

Stereo Inputs
Stereo Line
1/4" TRS connector balanced
Frequency response: 20 Hz to 200 kHz
Impedance: 22 kΩ balanced, 10 kΩ unbalanced
Max input level @ 0 dB Gain: +21 dBu

STREAM Inputs (Analog)
RCA connector unbalanced
Impedance: 10 kΩ unbalanced
Max input level: 10 dBu

Equalizer
Low: 80 Hz/±15 dB
Mid: 2.5 kHz/±15 dB
High: 12 kHz/±15 dB

Main, Monitor & FX Send Outputs
Type: 1/4" TRS connector impedance-balanced
Impedance: 120 Ω
Max output level: 21 dBu

Phones Out
Type: 1/4" TRS connector unbalanced
Impedance: 23 Ω
Max output level: 19 dBu/150 Ω

STREAM out (Analog)
Type: RCA connector unbalanced
Impedance: 1 kΩ unbalanced
Max output level: 10 dBu

Main Mix noise
Main Mix @ -∞: -109 dBu A-weighted
Channel @ -∞: -109 dBu A-weighted

USB
Type: Type-B connector
USB Audio Data: 48 kHz 16 bit
UAC2 Class Compliant: stereo in/out

Power Supply
Power Consumption: 12 W
Adaptor input: 100 - 240 V~, 50/60 Hz, 0.5 A
Adaptor output: 18 V DC 1.0 A
